Four-stroke Eight-wheel Wire Drawing Machine
Four-stroke Eight-wheel Wire Drawing Machine
This professional bamboo drawing machine is dedicated to forming bamboo strips into standard-sized bamboo filaments. With a precision shaping structure, it ensures uniform diameter and smooth surface of the finished filaments, which can be directly connected to subsequent processes such as fixed-length cutting and polishing. It serves as the core forming equipment for production lines of fine bamboo products including bamboo toothpicks, barbecue skewers and food-grade bamboo sticks.
Couldn't load pickup availability
| Voltage | 380V |
|---|---|
| Motor Power | 13.2KW |
| Machine Size | L: 1300 mm W: 1100 mm H: 1150 mm |
| Machine Weight | 750KG |
| Output | Drawing Speed: 85 m/min |
Function
This bamboo drawing machine is dedicated to the fine drawing and shaping of bamboo strips, processing regular bamboo strips into uniform bamboo filaments. It only extracts the yellow bamboo layer to make filaments and precisely removes the green bamboo layer during production. The finished bamboo filaments feature consistent diameter, uniform toughness and stable quality, serving as core equipment for production lines of high‑quality bamboo toothpicks, barbecue skewers and other fine bamboo products.
-
